SPRAY GUNS

ELECTRIC SPRAY GUNS



P120 H.V.L.P. FLOOR BASED ELECTRIC SPRAY GUN


 220V - 50/60 HZ
Nozzle: Ø
1,8 mm.
Tank: 700 ml.
Maximum flow: 320 ml/min.
High viscosity: 50 Din-s
Weight: 2,5 Kg.
Power: 500 watts




Ideal for wood sealers, varnishes spraying water & solvent paints and other non-abrasive materials.

Include: Turbine with gun holder, painting spray
gun, air filter, air hose 1,8 mm x Ø 25, viscosity test bucket,
conveyor belt.











P130 H.V.L.P. ELECTRIC SPRAY GUN


 220V - 50/60 HZ
Nozzle:
Ø 1,8 mm.
Tank: 700 ml.
Maximum flow: 280 ml/min.
High viscosity: 30 Din-s
Weight: 1,6 Kg.
Power: 400 watts




Ideal for spraying water & solvent paints, wood sealers, varnishes
and other non-abrasive materials.






NEUMÁTIC GUNS



   P700B

SPRAY GUN SET - H.V.L.P. GRAVITY SPRAY GUN WITH MANOMETER


Working Pressure: 3 bar / 43 psi
600 cc Plastic tank

Fluid nozzle 1.4 mm.

Stainless steel nozzle and needle. Aluminum body.
Transference efficiency over 75%.
Holder cup for diposable liners
5 individual 260 cc disposable liners.
Includes: plastic case, plastic filter, disassembly and cleaning kit, instructions and dissasembly manual.
Suitable for all waterborne and solvent-base material.
Includes a holder cup for diposable liners to make a quick change of the painting.



  P300

DRYWALL TEXTURE HOPPER GUN

Working Pressure: 4 bar / 58 psi
Tank: 5,5 L

For plastic coating application athome and construction work.
Gravity system.
Aluminum body.
5.5 Liter plastic hopper with handle.
Ergonomic trigger with retaining lock made to prevent fatigue.
No material waste.
Suitable for medium and high viscocity materials.
Rate regulator.
3 Nozzles: 4,0 and 6,0 mm for medium viscosity materials; and 8,0 mm for high viscosity materials.
1 Aluminum connector.
Dissasembly Manual.




 P700

H.L.V.P. GRAVITY
Work pressure: 3 BAR Máx.
Tank: 600cc


   P600

HALF PRESSURE SUCTION SYSTEM
Work pressure: 3,5 BAR Máx.
Tank: 1000cc


   P800

H.L.V.P. GRAVITY SYSTEM MICRO GUN - AEROGRAPH
Work pressure: 3 BAR Máx.
Tank: 125cc


   P900

HIGH VISCOSITY GRAVITY SYSTEM
Work pressure: 3.5 BAR Máx.
Tank: 600cc


  P400

SYSTEM GRAVITY
Work pressure: 4 BAR Máx.
Tank: 500cc

   P500

SYSTEM SUCTION
Work pressure: 4 BAR Máx.
Tank: 1000cc

   PAK

PENCIL-LIKE AIRBRUSH KIT
Work pressure: 1 a 3,5 BAR
Spray: 40 a 60 mm




FILTERS & ACCESSORIES


  A221
FILTER + REGULATOR

Max. press: : 9,6 bar / 140 psi
Air Intake: 1/4"
Filtered: 40 µ.


Info: Pressure Range: 0,7 - 8,3 bar / 10-120 psi. Maximum temperature: 60°C. In blister.
  A222
FILTER

Max. press: : 9,6 bar / 140 psi
Air Intake: 1/4"
Filtered: 40 µ.


Info: Pressure Range: 0,7 - 8,3 bar / 10-120 psi. Maximum temperature: 60°C. In blister.
  A220
AIR UNIT - FILTER + REGULATOR

Max. press: : 9,6 bar / 140 psi
Air Intake: 1/4"
Filtered: 40 µ.


Info: Pressure Range: 0,7 - 8,3 bar / 10-120 psi. Maximum temperature: 60°C. In blister.
  A223
OILER

Max. press: : 9,6 bar / 140 psi
Air Intake: 1/4"
Filtered: 40 µ.


Info: Pressure Range: 0,7 - 8,3 bar / 10-120 psi. Maximum temperature: 60°C. In blister.

SPRAY GUN HOLDER

  PT10
Type: 2 Pieces

To hold, fill and strain the paint in the spray gun.
Compatible with most of the Mota gravity spray guns.
Drilled holes to mount on bech work or walls.
Removable strainer holder.
Includes 5 paint strainers.
It does not include any spray gun.
  PT11
Type: Magnetic
It adhere to any flat ferrous surface such as work bench, tool boxes, car bodyworks, etc.
46 mm Steel hook with protective plastic coating.
Compatible with most of the Mota gravity spray guns.
SPRAY GUN STRAINER

  PT12
Type: Paper y Nylon.
